1. Main Floor System
- Adjustable steel tele-posts
- Built up wood support beam
- 5-½” sill sealer gasket
- 2x6 pressure treated sill plate
- Wood I pre-engineered floor joist system
- 5/8" t&g OSB sub-floor sheathing
- Builders shims
- 1x8 t&g, v-joint pine skirting
2. Perimeter Wall System
- Prefabricated wall panels (8’ high) constructed of 2x6 framing @16” o.c., R-4 Insulated sheathing, air barrier, & 1x3 strapping. Openings prepared with appropriate lintels
- 1x8 t&g, v-joint pine siding
- R-20 fiberglass insulation
3. Windows and Doors – Energy Star Rated
- White P.V.C., 4-1/2” flush frame, Low-E argon thermal glass, insect screens.
- Steel insulated entrance systems
- 7-1/4" flush pine frame- white vinyl clad, Low-E argon thermal glass
4. Interior Partition Framing
- 2x4 (or 2x6 as required) spruce, plates & studs @ 16” o.c.
5. Second Floor System (when applicable)
- Pine timber support posts
- 6x12 pine supprt beams
- 6x8 pine timber floor joists 32” o.c.
- 5/8" t&g OSBsub-floor sheathing
6. Gable Ends
- 2x6 spruce framing – plates and studs
- Lintel material – as required
- Insulated wall sheathing – R4
- House wrap – air barrier
- 1x3 strapping
- 1x8 t&g, v-joint pine siding
- *and second floor walls when applicable
7. Roof System
- Pre-engineered roof system
- Structural beams and support posts as required
- Truss bracing material – as required
- ½” OSB sheathing
- 15 lb building paper for eaves and rakes
- Roof shingles
- Pre-finished steel flashings
- Roof vents
- Sub-fascia – 2x4 spruce
